Hot Selling ASTM A179 19.05mm x 2.11mm Seamless Carbon Steel Pipe/Tube For Boiler And Heat Exchanger
Key Specifications / Features
Model No.: HX-Carbon steel pipe-03 Hits: 3
China manufacturer of Hot Selling ASTM A179 19.05mm x 2.11mm Seamless Carbon Steel Pipe/Tube For Boiler And Heat Exchanger
Request a quote
Share
Tags:
Detail Information
Standard: ASTM A179
Steel Grades: A179
Size Range: OD:12.7mm TO 220mm. WT: 2.11mm To 25.4mm
Manufacturing Process : Cold Drawn , Cold Rolled
Application:Tubes are used in boiler ,heat exchanger ,and superheater Etc.
Packing: External Black Painting ,Both Side With End Caps, In Bundles by Steel Strips,Covered by Waterproof.
Quality Certificate:ISO, API, Mill Test Certificate
Steel Grades: A179
Size Range: OD:12.7mm TO 220mm. WT: 2.11mm To 25.4mm
Manufacturing Process : Cold Drawn , Cold Rolled
Application:Tubes are used in boiler ,heat exchanger ,and superheater Etc.
Packing: External Black Painting ,Both Side With End Caps, In Bundles by Steel Strips,Covered by Waterproof.
Quality Certificate:ISO, API, Mill Test Certificate
| Standard | Outside Diamater | OD Tolerance | Wall Thickness | Wall Thickness Tolerance |
| ASTM A179 ASTM A192 ASTM A210 |
≤25.4mm | ±0.10mm | All Thickness | +20% -0% |
| 25.4mm-38.1mm | ±0.15mm | +20% -0% | ||
| 38.1mm-50.8mm | ±0.20mm | All Thickness | +22% -0% | |
| 50.8mm-63.5mm | ±0.25mm | +22% -0% | ||
| 63.5mm-76.2mm | ±0.30mm | +22% -0% | ||
| 76.2mm-101.6mm | ±0.38mm | +22% -0% | ||
| 101.6mm-190.5mm | +0.38mm -0.64mm | +22% -0% | ||
| 190.5mm-228.6mm | +0.38mm -1.14mm | +22% -0% |
Standard |
Steel Grade |
Chemical components | Mechanical performance | ||||||||
| C | Si | Mn | P、S | Cu | Ni | Mo | Tensile Strenght (Mpa） |
Yield Strenght (Mpa) |
Elongation (%) |
||
| ASTM A179 |
A179 | 0.06～0.18 | ／ | 0.27～0.63 | ≤0.035 | ／ | ／ | ／ | ≥325 | ≥180 | 35 |
| ASTM A192 |
A192 | 0.06～0.18 | ≤0.25 | 0.27～0.63 | ≤0.035 | ／ | ／ | ／ | ≥325 | ≥180 | 35 |
| ASTM A210 |
A210A1 | ≤0.27 | ≥0.10 | ≤0.93 | ≤0.035 | ／ | ／ | ／ | ≥415 | ≥255 | ≥30 |
| A210-C | ≤0.35 | ≥0.10 | 0.29～1.06 | ≤0.035 | ／ | ／ | ／ | ≥485 | ≥275 | ≥30 | |
