ELB,90 LR,UNS N08825,10S,2in,SR,BW
Key Specifications / Features
Model No.: HX-ELBOW Hits: 1
ELB,90 LR,WPNICMC,10S,2in,SR,BW
Butt-weld pipe elbows
Design spec ASME B16.9
Dimensional spec ASME B36.10M
Mat NICKEL ALLOY INCONEL 825
Mat spec, fitting ASTM B366 GRADE WPNICMC
UNS N08825
Manufacturing process SEAMLESS
Service SOUR
Service requirement NACE MR 01-75
Angle 90°
Type LONG RADIUS
Schedule number S-10S
Thickness, wall 2.77 mm
Size 50 mm
Request a quote
Share
Butt-weld pipe elbows
Design spec ASME B16.9
Dimensional spec ASME B36.10M
Mat NICKEL ALLOY INCONEL 825
Mat spec, fitting ASTM B366 GRADE WPNICMC
UNS N08825
Manufacturing process SEAMLESS
Service SOUR
Service requirement NACE MR 01-75
Angle 90°
Type LONG RADIUS
Schedule number S-10S
Thickness, wall 2.77 mm
Size 50 mm
Tags
Previous: ELB, 90 LR, WPL6, 40, 6 in, SR, BW
Detail Information
Type: Elbow, Equal Tee, Reducer , Caps, Hot Induction Bend
Standard: ASME B16.9,ASME B16.11,B16.25,MSS SP.75,SP97,ASME B16.49,EN10253
Material:
Carbon steel (ASTM A234 WPB/WPC,API 5L Gr.B X42-X70, S235/S355,P235/P355,A420 WPL6 A105,A694 F42-F70,A350 LF1/LF2)
Stainless steel (ASTM A403 WP304/WP316/WP321/WP347,A815 UNS S31803/S32205/ S32750/S32760, A182 F304/F316/F321/F347,F51/F53/F55)
Alloy steel (ASTM A234 WP11/WP/12/WP22/WP5/WP9/WP91,A182 F11/F12/F22/F5/F9/F91)
Size Range: 1/2”-36”
Marking: According to the standard
Surface: Painting or at buyer’s option
Third Party Inspection: SGS BV etc.
Packing: By Wooden Case or Pallet
Payment Term: At buyer’s option
