ASME B16.47 Forged Class250 Lap Joint Flange
Key Specifications / Features
Model No.: HX- Flange- 44 Hits: 7
China ASME B16.47 Lap Joint Flange, Forged Lap Joint Flange, Class250 Lap Joint Flange, Lap Joint Flange, Flange
Request a quote
Share
Tags:
Detail Information
Type: Lap Joint
Standard: ASME B16.47
Material: A105
Manufacturing Method: Forged
Pressure: Class250
Surface: Oiled , Painted
Third Party Inspection: SGS BV etc.
Packing: By Wooden Case or Pallet
Payment Term: At buyer’s option
Standard: ASME B16.47
Material: A105
Manufacturing Method: Forged
Pressure: Class250
Surface: Oiled , Painted
Third Party Inspection: SGS BV etc.
Packing: By Wooden Case or Pallet
Payment Term: At buyer’s option
| Flange Type | specification | ||||||||||
| ASME/ANSI B16.5 | ASME B16.47 Series A (or MSS SP-441) | ASME B16.47 Series B (or API 6052) | BS 4505 (ISO 7005-1) | BS 3293 | |||||||
| Nominal Size | |||||||||||
| ＜NPS26 | ≥NPS 26 | ≥NPS 26 | DN 10 to DN 4000 | ≥NPS 26 | |||||||
| NominalPressure(Class) | |||||||||||
| Class(lb) | Class(lb) | Class(lb) | PN(bar) | Class(lb) | |||||||
| Lap Joint | 150-2500 | - | - | 6-403 | - | ||||||
